RFC 4072S
242 / 272 PHOENIX CONTACT 108580_en_02
F_Source_Address F-Parameter (F_Source_Add for short);
PROFIsafe source address, address of the safety-related SPNS PROFINET controller (F-
Host)
F_Destination_Address F-Parameter (F_Dest_Add for short);
PROFIsafe destination address; address of the PROFIsafe device (F-Device)
iParameters Individual safety parameters of a device
Consecutive number See “Consecutive number”
Passivation If the safety module detects an error, it switches the affected channel or all channels of the
module to the safe state; the channels are then passivated. The detected errors are reported
to the safety-related controller.
For a safe input module, when passivation is enabled, substitute values (0) are provided for
the safety program instead of the process values present at the safe inputs.
For a safe output module, when passivation is enabled, substitute values (0) are transferred
to the safe outputs instead of the output values provided by the safety program.
PROFIsafe Safety-related bus profile based on PROFIBUS DP or PROFINET. It defines the communi-
cation between a safety program and the safe I/O devices in a safe system.
PROFIsafe address Each safe module has a PROFIsafe address. This address must be set on the safety module
via DIP switches, for example, and then configured in the configuration tool for the safety-
related controller used.
PROFIsafe monitoring
time
Monitoring time for safety-related communication between the iSPNS 3000 and the safe I/O
devices.
This time is parameterized in the F_WD_Time F-Parameter.
