 DA MAC Mask
Specify whether frames can hit the action according to their sender hardware
address field (SHA) settings.
 0: ARP frames where SHA is not equal to the DA MAC address.
 1: ARP frames where SHA is equal to the DA MAC address.
 SA MAC
Specify the source MAC filter for this ACE.
 Any: No SA MAC filter is specified.
 User Defined: If you want to filter a specific source MAC address with this
ACE, choose this value. A field for entering a SA MAC value appears.
When "User D
efined" is selected for the SA MAC filter, you can enter a specific
source MAC address. The legal format is "xx-xx-xx-xx-xx-xx". A frame that hits
this ACE matches this SA MAC value.
 SA MAC Value
 SA MAC Mask
Specify whether frames can hit the action according to their sender hardware
address field (SHA) settings.
 0: ARP frames where SHA is not equal to the SA MAC address.
 1: ARP frames where SHA is equal to the SA MAC address.
Indicates the ID of this pa
rticular VLAN.
 VLAN ID
Include or e
xclude the 802.1p value
 802.1p
Set the 802.1p
value.
 802.1p Value
 802.1p Mask
 0: where frame is not equal to the 802.1p value.
 1: where frame is equal to the 802.1p value.
You can enter a specific EtherType value. The allowed range is 0x05DD to
0xFFFF. A frame that hits this ACE matches this EtherType value.
 Ethertype
(Ran
ge:0x05DD –
0xFFFF)
Buttons
: Click to add ACE list.
Figure 4-10-4 MAC-based ACE Table page screenshot
The page includes the following fields:
Object Description
 ACL Name
Display the current ACL name
252
