User’s Manual of GSD-1002M
The page includes the following fields:
Object Description
Select ACL
name for this drop down list.
 ACL Name
Set the ACL
sequence.
 Sepuence
 Action
Indicates the forwarding action of the ACE.
 Permit: Frames matching the ACE may be forwarded and learned.
 Deny: Frames matching the ACE are dropped.
 Shutdown: Port shutdown is disabled for the ACE..
 Protocol
Specify the protocol filter for this ACE.
 Any(IP): No protocol filter is specified.
 Select from list: If you want to filter a specific protocol with this ACE, choose
this value and select protocol for this drop down list.
 Protocol ID to match: I If you want to filter a specific protocol with this ACE,
choose this value and set currect protocol ID.
 Source IP Address
Specify the Source IP address filter for this ACE.
 Any: No source IP address filter is specified.
 User Defined: If you want to filter a specific source IP address with this ACE,
choose this value. A field for entering a source IP address value appears.
When "User D
efined" is selected for the source IP address filter, you can enter a
specific source IP address. The legal format is "xxx.xxx.xxx.xxx". A frame that
hits this ACE matches this source IP address value.
 Source IP Address
Value
When "User D
efined" is selected for the source IP filter, you can enter a specific
SIP mask in dotted decimal notation.
 Source IP Wildcard
Mask
 Destination IP Address
Specify the Destination IP address filter for this ACE.
 Any: No destination IP address filter is specified.
 User Defined: If you want to filter a specific destination IP address with this
ACE, choose this value. A field for entering a source IP address value
appears.
 Destination IP Address
Value
When "User Defined" is selected for the destination IP address filter, you can
enter a specific destination IP address. The legal format is "xxx.xxx.xxx.xxx". A
frame that hits this ACE matches this destination IP address value.
When "User D
efined" is selected for the destination IP filter, you can enter a
specific DIP mask in dotted decimal notation.
 Destination IP
Wildcard Mask
 Source Port
Specify the source port for this ACE.
 Any: No specifc source port is specified (source port status is "don't-care").
 Single: If you want to filter a specific source port with this ACE, you can
enter a specific source port value. A field for entering a source port value
appears. The allowed range is 0 to 65535. A frame that hits this ACE
