User’s Manual of GSD-1002M
matches this source port value.
 Range: If you want to filter a specific source port range filter with this ACE,
you can enter a specific source port range value. A field for entering a source
port value appears. The allowed range is 0 to 65535. A frame that hits this
ACE matches this source port value.
 Destination Port
Specify the destination port for this ACE.
 Any: No specifc destination port is specified (destination port status is
"don't-care").
 Single: If you want to filter a specific destination port with this ACE, you can
enter a specific destiantino port value. A field for entering a destiantino port
value appears. The allowed range is 0 to 65535. A frame that hits this ACE
matches this destination port value.
 Range: If you want to filter a specific destiantion port range filter with this
ACE, you can enter a specific destiantion port range value. A field for
entering a destination port value appears.
UGR Specify the TCP "Urgent Pointer field significant" (URG) value for this
ACE.
 Set: TCP frames where the URG field is set must be able to match
this entry.
 Unset: TCP frames where the URG field is set must not be able to
match this entry.
 Don’t Care: Any value is allowed ("don't-care").
ACK Specify the TCP "Acknowledgment field significant" (ACK) value for this
ACE.
 Set: TCP frames where the ACK field is set must be able to match
this entry.
 Unset: TCP frames where the ACK field is set must not be able to
match this entry.
 Don’t Care: Any value is allowed ("don't-care").
PSH Specify the TCP "Push Function" (PSH) value for this ACE.
 Set: TCP frames where the PSH field is set must be able to match
this entry.
 Unset: TCP frames where the PSH field is set must not be able to
match this entry.
 Don’t Care: Any value is allowed ("don't-care").
 TCP Flags
RST
 Specify the TCP "Reset the connection" (RST) value for this ACE.
Set: TCP frames where the RST field is set must be able to match
this entry.
 Unset: TCP frames where the RST field is set must not be able to
match this entry.
257
