Planet IGS-10020MT User Manual

User’s Manual of IGS-10020MT
Read more about Guest VLANs here.
Port Counters
Object Description
These supplicant frame counters are available for the following administrative states:
Force Authorized
Force Unauthorized
Port-based 802.1X
Single 802.1X
Multi 802.1X
Direction Name IEEE Name Description
Rx
Total
dot1xAuthEapolFrames
Rx
The number of valid EAPOL
frames of any type that have
been received by the switch.
Rx
Response ID
dot1xAuthEapolRespId
FramesRx
The number of valid EAPOL
Response Identity frames
that have been received by
the switch.
Rx
Responses
dot1xAuthEapolRespFr
amesRx
The number of valid EAPOL
response frames (other than
Response Identity frames)
that have been received by
the switch.
Rx
Start
dot1xAuthEapolStartFra
mesRx
The number of EAPOL Start
frames that have been
received by the switch.
Rx
Logoff
dot1xAuthEapolLogoffFr
amesRx
The number of valid EAPOL
Logoff frames that have
been received by the switch.
 EAPOL Counters
Rx
Invalid Type
dot1xAuthInvalidEapolF
ramesRx
The number of EAPOL
frames that have been
received by the switch in
which the frame type is not
recognized.
248

Planet IGS-10020MT Specifications

General

Switch type	Managed
Switch layer	L2+
Quality of Service (QoS) support	Yes
SFP module slots quantity	2
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	8
10G support	No
Number of VLANs	255
Networking standards	IEEE 1588, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1ad, IEEE 802.1ag, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ah, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Copper ethernet cabling technology	1000BASE-T, 100BASE-TX, 10BASE-T
Security algorithms	802.1x RADIUS, SSH, SSL/TLS
Throughput	14.8 Mpps
Jumbo frames	9000
MAC address table	8000 entries
Stackable	-
Certification	FCC Part 15 Class A, CE
Product color	Black
Housing material	Aluminum
International Protection (IP) code	IP30
Power consumption (typical)	10 W
Heat dissipation	34 BTU/h
Operating temperature (T-T)	-40 - 75 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	87.8 mm
Width	56 mm
Height	135 mm
Weight	720 g
