Planet IGS-10020MT User Manual

User’s Manual of IGS-10020MT
Rx
Invalid Length
dot1xAuthEapLengthErr
orFramesRx
The number of EAPOL
frames that have been
received by the switch in
which the Packet Body
Length field is invalid.
Tx
Total
dot1xAuthEapolFrames
Tx
The number of EAPOL
frames of any type that have
been transmitted by the
switch.
Tx
Request ID
dot1xAuthEapolReqIdFr
amesTx
The number of EAPOL
Request Identity frames that
have been transmitted by
the switch.
Tx
Requests
dot1xAuthEapolReqFra
mesTx
The number of valid EAPOL
Request frames (other than
Request Identity frames)
that have been transmitted
by the switch.
These backend (RADIUS) frame counters are available for the following administrative
states:
Port-based 802.1X
Single 802.1X
Multi 802.1X
MAC-based Auth.
Direction Name IEEE Name Description
 Backend Server
Counters
Rx
Access
Challenges
dot1xAuthBackendAcce
ssChallenges
802.1X-based:
Counts the number of times
that the switch receives the
first request from the backend
server following the first
response from the supplicant.
Indicates that the backend
server has communication
with the switch.
MAC-based:
Counts all Access Challenges
received from the backend
249

Planet IGS-10020MT Specifications

General

Switch type	Managed
Switch layer	L2+
Quality of Service (QoS) support	Yes
SFP module slots quantity	2
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	8
10G support	No
Number of VLANs	255
Networking standards	IEEE 1588, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1ad, IEEE 802.1ag, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ah, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Copper ethernet cabling technology	1000BASE-T, 100BASE-TX, 10BASE-T
Security algorithms	802.1x RADIUS, SSH, SSL/TLS
Throughput	14.8 Mpps
Jumbo frames	9000
MAC address table	8000 entries
Stackable	-
Certification	FCC Part 15 Class A, CE
Product color	Black
Housing material	Aluminum
International Protection (IP) code	IP30
Power consumption (typical)	10 W
Heat dissipation	34 BTU/h
Operating temperature (T-T)	-40 - 75 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	87.8 mm
Width	56 mm
Height	135 mm
Weight	720 g
