User’s Manual of IGS-10020MT
Buttons
: Click to add a new user.
Add / Edit User
This page configures a user – add, edit or delete user.
Figure 4-2-5: Add / Edit User Configuration Page Screenshot
The page includes the following fields:
Object Description
User Name
A string identifying the user name that this entry should belong to. The allowed
string length is 1 to 32. The valid user name is a combination of letters, numbers
and underscores.
Password
The password of the user. The allowed string length is 0 to 32.
Privilege Level
The privilege level of the user. The allowed range is 1 to 15. If the privilege level
value is 15, it can access all groups, i.e. that is granted the fully control of the
device. But others value need to refer to each group privilege level. User's
privilege should be same or greater than the group privilege level to have the
access of that group. By default setting, most groups privilege level 5 has the
read-only access and privilege level 10 has the read-write access. And the
system maintenance (software upload, factory defaults and etc.) need user
privilege level 15. Generally, the privilege level 15 can be used for an
administrator account, privilege level 10 for a standard user account and privilege
level 5 for a guest account.
Buttons
: Click to save changes.
: Click to undo any changes made locally and revert to previously saved values.
: Click to undo any changes made locally and return to the Users.
59

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Planet IGS-10020MT and is the answer not in the manual?

Planet IGS-10020MT Specifications

General IconGeneral
Switch typeManaged
Switch layerL2+
Quality of Service (QoS) supportYes
SFP module slots quantity2
Installed SFP modules quantity0
Basic switching RJ-45 Ethernet ports typeGigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity8
10G supportNo
Number of VLANs255
Networking standardsIEEE 1588, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1ad, IEEE 802.1ag, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ah, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Copper ethernet cabling technology1000BASE-T, 100BASE-TX, 10BASE-T
Security algorithms802.1x RADIUS, SSH, SSL/TLS
Throughput14.8 Mpps
Jumbo frames9000
MAC address table8000 entries
Stackable-
CertificationFCC Part 15 Class A, CE
Product colorBlack
Housing materialAluminum
International Protection (IP) codeIP30
Power consumption (typical)10 W
Heat dissipation34 BTU/h
Operating temperature (T-T)-40 - 75 °C
Operating relative humidity (H-H)5 - 95 %
Harmonized System (HS) code85176990
Weight and Dimensions IconWeight and Dimensions
Depth87.8 mm
Width56 mm
Height135 mm
Weight720 g
