Chapter 5 Service Instructions
HF Series X-ray Generators - Service Manual Revision W
Quantum Medical Imaging, LLC
5-55
Service Checksum Report
Figure 5-5. Service Checksum Report Screen
The Service Checksum Report screen, shown above, lists the software
revision levels and checksum values for the various programmed devices
used in the generator and for the database loaded into OCP Data Mem-
ory. The OCP Microcontroller Board A16A1 contains flash memory that is
loaded with the indicated versions (and checksums) of internal and exter-
nal programs (in addition to that in the microcontroller) and databases.
To return to the main Service Menu, press the key next to Main field.
INTERNAL/
EXTERNAL
PROGRAMMED
MEMORY
VERSIONS
INTERNAL/
EXTERNAL
PROGRAMMED
MEMORY
CHECKSUMS
To Next Page
