Quantum ODYSSEY HF Series User Manual

Appendix D Calibration (Using Generator Service Tools)
HF Series X-ray Generators - Service Manual Revision W
Quantum Medical Imaging, LLC D-53
• KV - Calibrates the tube voltage settings used in conjunction with a
particular Receptor/Film Screen and ion chamber combination
• Copy - The Copy Receptor Calibration utility enables stored AEC
calibration data (kV curves, AEC offset data) to be copied from a
calibrated receptor/film screen to another receptor/film screen in order
to reduce overall calibration time.
IMPORTANT! When calibrating AEC using a wall
stand mounted receptor, ensure that the x-ray
beam is perpendicular to image receptor and that
the correct ion chamber detector(s) is selected.
Proceed as follows:
1. Factory Reset check box - when selected, will reset AEC Calibration
values to factory default settings. This normally should not be selected;
it should only be selected when calibration values are extraordinarily out-
of-range (usually signifying a hardware or software abnormality).
