Quantum ODYSSEY HF Series User Manual

Chapter 2 Assembly & Installation
Revision W HF Series X-ray Generators - Service Manual
2-30 Quantum Medical Imaging
Tube Rotor Cable (Systems with Internal High Speed Starter Q-
HSS Option Only)
The Q-HSS High Speed Starter is factory pre-configured for the x-ray tube
supplied with the generator and, with the exception of the Rotor Cable, does
not require any field connections or adjustments. Tables 2-3a and 2-3b are
provided in the event tube replacement is necessary or if the HSS Power
Driver Board AY40-036S needs replacement. The table indicates the proper
connections of the various transformer voltage inputs (380, 220, 120, 80, 60
and 0 VAC) to the HSS Driver Board at Terminal Block TB1 for each of the
compatible tubes used with the generator.
Also, ensure the generator is configured with the correct value rotor capaci-
tors for the installed tube as indicated in Table 2-3a.
If not already connected, connect transformer input wires to HSS Driver
Board AY40-036S terminal block TB1 plug for correct tube type in accordance
with table below:
Table 2-3a: Quantum High-Speed Starter Rotor Phase Capacitor Configuration
Tube Type Rotor Phase Capacitors
E7813X, E7252X, E7869X Install one (1) 40 uF cap (low speed), two (2) 12 uF in series
(high speed)
E7254X, all Varian, all
Dunlee (except MX100 GE
replacement, see below)
Install one (1) 25 uF cap (low speed), two (2) 12 uF in series
(high speed)
Dunlee MX100 Replace-
ment for GE Radiographic
System
Install one (1) 25 uF cap (low speed), two (2) 15 uF in series
(high speed)
Table 2-3b: HSS Driver Board AY40-036S Boost and Run Voltage Requirements: Transformer
Input Wires to Terminal Block Plug TB1
TB1-1 TB1-3 TB1-5 TB1-6 TB1-7
TUBE MODEL
HIGH SPEED
BOOST
VOLTAGE
LOW SPEED
BOOST
VOLTAGE
HIGH SPEED
RUN
VOLTAGE
LOW SPEED
RUN
VOLTAGE
COMMON
TOSHIBA E7255,
E7254
WIRE #5
(380 VAC)
WIRE #4
(220 VAC)
WIRE #3
(120 VAC)
WIRE #2A
(80 VAC)
WIRE #1
(0 VAC)
TOSHIBA E7252,
E7813
WIRE #4
(220 VAC)
WIRE #3
(120 VAC)
WIRE #2A
(80 VAC)
WIRE #2
(60 VAC)
WIRE #1
(0 VAC)
