Quantum ODYSSEY HF Series User Manual

Chapter 2 Assembly & Installation
HF Series X-ray Generators - Service Manual Revision W
Quantum Medical Imaging 2-51
7. On the Generator Help Services screen, select Service option. The General
Service Options Menu appears:
Figure 2-25c. General Service Options Menu
8. Select Network Settings. The following screen appears:
Figure 2-25d. Network Settings Screen
9. The Network Settings Screen displays the network configuration settings of
the personal computer housed within the all-in-one Q-VISION operator con-
trol panel. Verify the fields are set as follows:
