Chapter 8: Maintenance ABL77 Service Manual
Cleaning, Continued
Waste drain
(continued)
Step Action
3.
If a sensor cassette is… then…
attached the analyzer will remove any fluid then
prompt you to remove the sensor
cassette. The analyzer will sense when
the cassette has been removed and will
automatically proceed to the next
screen.
not
attached the analyzer will automatically proceed
to the next screen.
4.
Ensure there is a cal pack in place to collect waste fluids. Introduce 1
cc of Cleaning Solution (REF: 943-906) into the waste drain (the
black opening located directly below the inlet probe when a cassette is
in place).
5.
Activate the waste pump by pressing Pump to carry this fluid through
the waste line and into the cal pack.
• Repeat as desired.
• Press OK.
6.
• Re-attach the sensor cassette
• Press OK.
The analyzer will automatically perform a 2-point calibration then
return to the Main Menu.
8-8 Rev. F
