Remote Control
R&S
®
FSPN
387User Manual 1179.4363.02 ─ 01
●
Stop frequency: [SENSe:]FREQuency:STOP
CONFigure:TRANsient:MODE.........................................................................................387
[SENSe:]FREQuency:CENTer:STEP................................................................................387
[SENSe:]FREQuency:CENTer:STEP:LINK........................................................................388
[SENSe:]FREQuency:CENTer:STEP:LINK:FACTor............................................................388
[SENSe:]FREQuency:SPAN............................................................................................389
CONFigure:TRANsient:MODE <OrderBy>
This command selects the transient measurement mode.
Parameters:
<OrderBy> NARRow
Narrowband mode: For measurement with a frequency span <
40 MHz.
If you define a span < 40 MHz while wideband is selected, or
define a frequency range outside the supported frequency
range, the R&S FSPN automatically selects narrowband mode
and adjusts the center, start and stop frequencies, if necessary.
WIDE
Wideband mode: For measurements with a frequency span > 40
MHz, but only in frequency range between 276 MHz and
7.980 GHz.
If you define a span > 40 MHz while narrowband mode is
selected, the R&S FSPN automatically selects wideband mode,
and adjusts the center, start and stop frequencies, if necessary.
*RST:
WIDE
Example: //Configure measurement with wideband mode
FREQ:CENT 1GHZ
FREQ:SPAN 100MHZ
CONF:TRAN:MODE?
//returns
WIDE
//Select narrowband mode instead - keeps center frequency but
reduces span
CONF:TRAN:MODE NARR
FREQ:CENT?
//returns
1000000000
FREQ:SPAN?
//returns
40000000
Manual operation:
See "Selecting the measurement mode" on page 132
[SENSe:]FREQuency:CENTer:STEP <Frequency>
This command defines a frequency stepsize.
Common Measurement Settings
