Getting started
R&S
®
TSMA6
21User Manual 4900.8057.02 ─ 11
3.1.5 Connecting antennas
The SMA connector is sensitive to mechanical stress. Use the following handling pre-
cautions.
●
Always use a torque wrench and mount the cable end with 60 Ncm.
●
Do not stack adapters directly at the SMA connector. If you need to use adapters
(e.g: SMA to N), then always use a specific adapter cable
(Rohde & Schwarz order no. 4900.1700.00).
To connect RF and GPS antenna
1. Connect the RF antenna to the RF IN connector (see Figure 3-7 - 14).
2. Connect the GPS antenna to the GPS ANT port (see Figure 3-7 - 4).
3.1.6 Connecting devices for local operation
To connect devices
► Connect mouse and keyboard to the USB 2.0 ports (see Figure 3-7 - 11) and a
monitor to the appropriate monitor port (HDMI, USB-C), (see Figure 3-7 - 13, 9).
3.1.7 Connecting to power
This section describes how to connect the R&S TSMA6 to a power supply unit.
3.1.7.1 Connecting to a vehicle DC power supply via cigarette lighter
The R&S TSMA6 is delivered with a 12 V DC power supply cable with a cigarette
lighter connector.
1. Check the rating of the vehicle DC power supply. It has to be 12 V@10A.
2. Connect the 7-pin connector to DC IN.
3. Connect the cigarette lighter adapter to the 12 V outlet of the vehicle.
3.1.7.2 Connecting to the vehicle power supply via terminal
1. Ensure that the rating of the DC supply network matches the requirements printed
on the casing next to the DC input, see (8) in Figure 3-7.
2. Demount the cigarette lighter adapter from the cable.
3. Connect the open ends of the cable to the DC supply.
Preparing for use
