R&S TSMA6 User Manual

Getting started
R&S
®
TSMA6
35User Manual 4900.8057.02 ─ 11
Configure the WLAN and Bluetooth settings via web-GUI.
●
Chapter A.2.2.1, "Bluetooth", on page 160
●
Chapter A.2.2.2, "WLAN", on page 161
●
Chapter A.2.2.3, "WLAN AP", on page 163
3.2.5 Status LEDs
The four LEDs on the rear panel display the following states.
●
[Scanner State / Scanner Pwr]
Indicates the state of the scanner component
●
[Mode]
Indicates the device status
●
[Meas]
Indicates the state of the SW application
Device Scanner
[Mode] LED [Meas] LED [Pwr] LED [State]LED Comment
Off Off Off Off Power Off
green (BLINKING, 1
Hz)
--- --- --- Power On Selftest /
Power Down
green (CONT.) --- --- --- Power On / WLAN
Off
blue (CONT.) --- --- --- Power On / WLAN
On
--- --- green (BLINKING
rapidly => ON)
red (Off-On < 5s => Off ) Scanner configura-
tion ongoing
--- --- green (CONT.) --- Scanner ready
--- yellow (CONT.) green (CONT.) green (BLINKING) SW loading
--- green (CONT.) green (CONT.) green (CONT.) SW ready
--- green (BLINKING, 0.5 Hz) green (CONT.) green (BLINKING) SW measuring
--- green/blue (BLINKING rapidly) green (CONT.) green (BLINKING) SW recording
--- yellow (BLINKING, 2 Hz) --- --- SW warning
blue (BLINKING, 1
Hz)
--- --- --- Restore/
Backup/FW, SW
installation (in pro-
gress)
green (BLINKING,
0.2 Hz, ton = 1 s)
--- --- --- Delayed start activa-
ted
Error States
blue (BLINKING
rapidly)
--- --- --- Selftest Failed/
Scanner Interface
not accessible
Instrument tour
