R&S TSMA6 User Manual

Getting started
R&S
®
TSMA6
34User Manual 4900.8057.02 ─ 11
●
Remote Control via Remote Desktop Connection
●
LAN interface in NESTOR Probe Mode
Table 3-1: LAN port LEDs
Status LED
Link status
yellow
Activity status
green
HDMI connector
See (16) in Figure 3-7.
Connecting an external monitor. (max. resolution: 2560 x 1600 pixel).
3.2.3 Built-In GPS receiver
The integrated multi-GNSS (GPS / BeiDou / Galileo / GLONASS) receiver allows to
use three satellite systems in parallel. It offers an accuracy improvement of 30 % to 50
% by using a second constellation of satellites.
Following combinations are allowed:
●
GPS only
●
GPS / GLONASS / Galileo
●
GPS / BeiDou
The R&S TSMA6 can perform dead reckoning in tunnels to provide position informa-
tion even if no satellites are available. The dead reckoning is performed by the device
with its built-in electronic gyroscopes.
For enabling untethered dead reckoning, see Chapter 3.1.13, "Calibrating GPS for
dead reckoning", on page 30.
Depending on the intended use, the respective valid regulations regarding lightning
protection of the antennas and regarding vehicle installation must be observed during
installation.
3.2.4 Built-In WLAN / Bluetooth adapter
The R&S TSMA6 has built-in WLAN/Bluetooth module (Intel
®
Wireless AC 8265).
The R&S TSMA6 WLAN / Bluetooth adapter allows the following modes.
●
Client connection to a distant WLAN network
●
Serving as a WLAN access point
Per default, the R&S TSMA6 WLAN access point is switched on. The login credentials
are found on the bottom label of the device. The WLAN / Bluetooth can be switched off
(flight mode) via rear panel switch.
Instrument tour
