Configuring the R&S TSMA6

R&S

TSMA6

52User Manual 4900.8057.02 ─ 11

Figure 6-5: Scanner ready

For more details about the QualiPoc configuration and usage, refer to the user docu-

mentation of QualiPoc

6.4.1.4 NESTOR and NESTOR probe mode

The NESTOR mode is only displayed if the NESTOR software is installed (see Chap-

ter 8.6.2, "R&S NESTOR software", on page 106).

General

●

NESTOR mode

The NESTOR UI engine and the NESTOR measurement engine are hosted on the

R&S TSMA6.

●

NESTOR probe mode

The R&S TSMA6 hosts only the NESTOR measurement engine. The NESTOR UI

engine is hosted on a remote PC connected via LAN/WLAN with the R&S TSMA6.

This master PC is required to control the measurement.

Prerequisites

●

For NESTOR and NESTOR probe mode:

– NESTOR option licenses are either installed on the internal SD card or connec-

ted as an external USB dongle

●

For NESTOR mode only:

– NESTOR workspace file imported (see "Import NESTOR workspace file"

on page 55

– NESTOR license dongle connected to a USB port

●

For NESTOR probe mode only:

– WAN / LAN connection with the NESTOR host (see Chapter 3.1.10, "Connect-

ing to LAN/WAN from a remote PC", on page 28)

– NESTOR Probe mode requires a master PC to control the measurement

– Optional: NESTOR license dongle connected to a USB port

Selecting measurement mode
