Configuring the R&S TSMA6
R&S
®
TSMA6
53User Manual 4900.8057.02 ─ 11
NESTOR mode
To use the R&S TSMA6 NESTOR mode, the following steps must be performed.
1. In the web-GUI, set the "Mode of Operation" to "NESTOR".
2. Select or unselect "Autostart".
● Unselected: NESTOR starts without workspace parameter and the workspace
selector box is inactive.
● Selected: Select a workspace file for mode activation. The workspace selector
box is active.
3. Select a scenario ("Monitoring" or "Cellular Network Analysis").
4. Press "Submit".
The R&S TSMA6 is switched into "NESTOR" mode. In the status bar, the entry is
"Changing mode of operation in progress...".
The selected mode is active when the status bar displays "No error". The scanner
"State" LED starts blinking rapidly.
NESTOR probe mode
1. On the "Mode" tab, select "NESTOR Probe" mode.
2. Press "Submit".
The R&S TSMA6 is switched into "NESTOR Probe" mode. In the status bar, the
entry is "Changing mode of operation in progress...".
The selected mode is active when the status bar indicates "No error". The scanner
"State" LED starts blinking rapidly.
The NESTOR measurement is started and controlled from the host PC.
Selecting measurement mode
