Applications
The HAS05 accessories are used to
• operate HMF01.1 motor filters at HCS03 drive controllers.
• operate HNK01.1 mains filters at HCS03 drive controllers.
HAS05 type Application
HAS05.1-001-NNN-NN is used for electrical connection
between motor filter HMF01.1A-D0K2-
D0045 and HCS03.1E-W0070, as well
as between mains filter HNK01.1A-
A075-E0050 and HCS03.1E-W0070
HAS05.1-002-NNN-NN is used for electrical connection
between mains filter HNK01.1A-A075-
E0050 and HCS03.1E-W0070, if a
motor filter has been mounted
between HCS03.1 and mains filter
Fig. 14-53: HAS05 type
Scope of Supply
The HAS05.1-001-NNN-NN and HAS05.1-002-NNN-NN accessories are
available as an option, they are not part of the standard scope of supply.
Accessories HAS05.1-001-NNN-NN
EKZU0001EN00.FH9
Fig. 14-54: Accessories HAS05.1-001

REXROTH IndraDrive C Specifications

General

Protection Class	IP20
Voltage Range	200 V to 480 V
Input Voltage	200 to 480 VAC
Control Modes	Speed, Torque, Position
Communication Interfaces	PROFIBUS, CANopen, Ethernet
Feedback Systems	Resolver, incremental encoder, absolute encoder
