Rexroth IndraDrive Accessories in the Drive System Rexroth IndraDrive 14-61
DOK-INDRV*-SYSTEM*****-PR02-EN-P
Mounting RKB bus cable:
1. Mount housing to ground strap.
2. Unscrew cover and plug ribbon cable of right device into circuit board.
3. Close cover.
4. Screw strain relief down to ground strap.
5. Plug ribbon cable into X1.
Note: Make sure the connection between strain relief and ground
strap is well conductive.
By means of appropriate wiring establish equipment grounding
connections of devices that are not directly adjoining.
How to Mount RKB Bus Cable
