Rexroth IndraDrive Configuration of the Drive System Rexroth IndraDrive 6-17
DOK-INDRV*-SYSTEM*****-PR02-EN-P
Supply unit Mains chokes Mains filters Explanation
integrated in HNK HNK01.1A-A075-E0106 standard for operating one drive
controller at the mains filter
HNL01.1E-0240-N0106 without standard for operating one drive
controller without mains filter
without HNF01.1A-F240-E0125 red. performance data see Project
Planning Manual of HSC03
HNL01.1E-0240-N0106 HNF01.1A-F240-E0125 standard for operating several drive
controllers at the mains filter
without HNF01.1A-M900-E0125 red. performance data see Project
Planning Manual of HSC03
HNL01.1E-0240-N0106 HNF01.1A-M900-E0125 standard for operating several drive
controllers at the mains filter
HCS03.1E-W0150
HNL01.1E-0240-N0106 with
HNL01.1E-2800-S0125
customer-side standard mains choke connected in
series with current-compensated
mains choke to reduce line-frequency
leakage currents
integrated in HNK HNK01.1A-A075-E0146 standard for operating one drive
controller at the mains filter
HNL01.1E-0170-N0146 without standard for operating one drive
controller without mains filter
without HNF01.1A-F240-E0202 red. performance data see Project
Planning Manual of HSC03
HNL01.1E-0170-N0146 HNF01.1A-F240-E0202 standard for operating several drive
controllers at the mains filter
without HNF01.1A-M900-E0202 red. performance data see Project
Planning Manual of HSC03
HNL01.1E-0170-N0146 HNF01.1A-M900-E0202 standard for operating several drive
controllers at the mains filter
HCS03.1E-W0210
HNL01.1E-0170-N0146 with
HNL01.1E-3400-S0202
customer-side standard mains choke connected in
series with current-compensated
mains choke to reduce line-frequency
leakage currents
Fig. 6-15: Mains connection phase HCS03
