REXROTH IndraDrive C User Manual

6-16 Configuration of the Drive System Rexroth IndraDrive Rexroth IndraDrive
DOK-INDRV*-SYSTEM*****-PR02-EN-P
HCS03 Drive Controllers
Supply unit Mains chokes Mains filters Explanation
integrated in HNK HNK01.1A-A075-E0050 standard for operating one drive
controller at the mains filter
HNL01.1E-0571-N0050 standard for operating one drive
controller at the mains filter
without HNF01.1A-F240-E0051 red. performance data see Project
Planning Manual of HSC03
HNL01.1E-0571-N0050 HNF01.1A-F240-E0051 standard for operating several drive
controllers at the mains filter
without HNF01.1A-M900-E0051 red. performance data see Project
Planning Manual of HSC03
HNL01.1E-0571-N0050 HNF01.1A-M900-E0051 standard for operating several drive
controllers at the mains filter
HCS03.1E-W0070
HNL01.1E-0400-N0051 with
HNL01.1E-5700-S0051
customer-side standard mains choke connected in
series with current-compensated
mains choke to reduce line-frequency
leakage currents
integrated in HNK HNK01.1A-A075-E0080 standard for operating one drive
controller at the mains filter
HNL01.1E-0362-N0080 standard for operating one drive
controller at the mains filter
without HNF01.1A-F240-E0125 red. performance data see Project
Planning Manual of HSC03
HNL01.1E-0362-N0080 HNF01.1A-F240-E0125 standard for operating several drive
controllers at the mains filter
without HNF01.1A-M900-E0125 red. performance data see Project
Planning Manual of HSC03
HNL01.1E-0362-N0080 HNF01.1A-M900-E0125 standard for operating several drive
controllers at the mains filter
HCS03.1E-W0100
HNL01.1E-0362-N0080 with
HNL01.1E-2800-S0125
customer-side standard mains choke connected in
series with current-compensated
mains choke to reduce line-frequency
leakage currents
