BRP-Rotax
REPAIR MANUAL
Figure 5.30: Insertion jig
1
Ball bearing 6206
2 Oil seal 10x26x7
3
Insertion jig
4
Oil seal 10x26x7 (open end)
______________________________________________________
Chapter 5
Page 34
Effectivity: 125 MAX evo, Junior MAX
evo, Mini MAX evo, Micro MAX evo
Edition - February 01 2018 /Rev. 0
