Sirius 800 Series User Manual Nucleus 2450 Router Controller Card Nucleus Router Control Modules 14.5
Iss 5 Rev 7 Page 274 © 2017 SAM
14.5.2.3 Sirius 850: Input Output Port Mapping
Sirius 850 Single Frame: Frame 1 of 1 (Frame ID Switch set to 0 - see section 16.3.1)
Table 76 shows the Sirius 850 crosspoint address mapping for Frame 1 of 1:
Expanded Sirius 850 Two Frame System
Sirius 850 frame one of two (Frame ID Switch set to 1 - see section 16.3.1)
Table 77 shows the Sirius 850 crosspoint address mapping for Frame 1 of 2:
Input/Output Range Addresses
Video Inputs 1 to 576 Source 0 to 575
Main Video Outputs 1 to 576 Destination 0 to 575
Expansion Video Outputs
(using 5928 expansion modules &
1366 expansion output
rear panels)
577 to 1152 576 to 1151
*Multiviewer Outputs
(using two 1291 multiviewer
rear panels)
1 to 96
Destination 1152 to 1199
&
Destination 1224 to 1271
Monitoring Outputs 1 to 4 Destination 16370 to 16373
Table 76 Sirius 850: Input Output Port Mapping (Frame 1 0f 1)
Note:
*Multiviewer Outputs: 1152 to 1291 only if two 1292 multiviewer MV-Link rear panels are
fitted - (no longer supplied)
Input/Output Range Addresses
Video Inputs 1 to 1152 Source 0 to 1151
Main Video Outputs
(using 5928 expansion modules &
1365/1290 expansion output
rear panels)
1 to 576 Destination 0 to 575
*Multiviewer Outputs
(using two 1291 multiviewer
rear panels)
1 to 96
Destination 1152 to 1199
&
Destination 1224 to 1271
Monitoring Outputs 1 to 4 Destination 16370 to 16373
Destinations 577 to 1152 are not used and do not respond to any control
Table 77 Sirius 850: Input Output Port Mapping (Frame 1 0f 2)
Note:
*Multiviewer Outputs: 1152 to 1291 only if two 1292 multiviewer MV-Link rear panels are
fitted - (no longer supplied)
