Sam Sirius 830 - Page 290

Sirius 800 Series User Manual Control/Fan Interface Module Compatibility Control/Fan Interface Module 15.1
Iss 5 Rev 7 Page 290 © 2017 SAM
Table 82 lists compatibility between the Sirius 800 modules and the control/fan interface
modules.
Modules
2457/2458
Control/Fan
Interface
Module
Compatibility
2455/2456
Control/Fan
Interface
Module
Compatibility
2452/2453
Control/Fan
Interface
Module
Compatibility
Nucleus Controllers
2450 - Nucleus Router Control Module No No Yes
2464/2463 - Nucleus2 Router Control
Module
Yes Yes Yes
Input Modules
5913 - Sirius 840/850 Standard Video BNC
Input module
Yes
(not Sirius 830)
Yes
(not Sirius 830)
Yes
(not Sirius 830)
5914 - Sirius 840/850 Standard Video Fiber
input module
Yes
(not Sirius 830)
Yes
(not Sirius 830)
Yes
(not Sirius 830)
5915 - Sirius 800 Video AHP input module Yes Yes No
5916 - Sirius 830 Standard Video BNC/Fiber
input module
Yes
(not Sirius
840/850)
Yes
(not Sirius
840/850)
Yes
(not Sirius
840/850)
5917 - Sirius 800 Standard Video BNC/Fibre
input module
Yes Yes Yes
5919 - Sirius 800 Video AHP input module
with delay and sync capability
Yes No No
4915 - Sirius 800 AES/MADI input module -
120 AES Pairs and up to 3 MADI inputs
or
4915 - Sirius 800 AES/MADI input module -
12 MADI (Main & Redundant)
Yes Yes No
Output Modules
5923 - Sirius 840/850 Standard Video BNC
output module
Yes
(not Sirius 830)
Yes
(not Sirius 830)
Yes
(not Sirius 830)
5924 - Sirius 840/850 Standard Video Fiber
output module
Yes
(not Sirius 830)
Yes
(not Sirius 830)
Yes
(not Sirius 830)
5925 - Sirius 800 Video AHP output module Yes Yes No
5926 - Sirius 800 Standard Video output
module (non-expandable)
Yes Yes Yes
5937 - Sirius 830 Standard Video BNC/Fiber
output module
Yes
(not Sirius
840/850)
Yes
(not Sirius
840/850)
Yes
(not Sirius
840/850)
5938
- Sirius 850 Standard Video output
module (expandable)
Only fitted if expansion is required between
two Sirius 850 frames
Yes
(not Sirius 830)
Yes
(not Sirius 830)
Yes
(not Sirius 830)
5949 - Sirius 800 Video embedding & AHP
output module with delay and sync capability
Yes No No
Table 82 Control/Fan Interface Module Compatibility Table.
