Sam Sirius 830 - Page 325

Sirius 800 Series User Manual Output Modules Modules No Longer Supplied With New Systems C.4
Iss 5 Rev 7 Page 325 © 2017 SAM
C.4.1.1 Duplicate MADI Outputs
When fitted with the 1295 or 1296 MADI rear panels the 4925 module outputs 12 MADI
channels and a further 12 duplicate MADI channels. The main and duplicate channels can be
used to give the MADI outputs resilience if the equipment receiving the outputs is capable of
automatically switching between main and backup feeds.
The main and backup connections are shown in the rear panel diagrams listed in Table 102
C.4.1.2 Configuring MADI to 56 or 64 Channels
Individual MADI channels are configured to output in 56 or 64 channel MADI using the
Workbench Online Editor.
Nucleus2 Router Control Module Navigate to:
Controller | Devices | Devices[1]: LocalRouterDevice |
LocalRouterConfig | ModuleConfigurations |
ModuleConfiguration[XXX]: AudioOutput | MADIControl |
MADIControl[YY] | Format=
Where:
XXX= the Module ID of the Audio Output Module (see the Workbench manual for details)
YY = the MADI channel (1 to 12) being configured
Select the number of MADI channels from the drop down menu:
• MADI56 = configures the MADI channel to 56 channels
• MADI64 = configures the MADI channel to 64 channels
Note:
• Jumpers and Headers are present on the audio output module and these are for
SAM Use Only.
• In normal operation no jumper links or headers are fitted except for PL2 which has
a link fitted across the two pins closest to the LEDs on the front of the module.
Rear Panel See Figure Number
1295 BNC rear panel See Figure 130 on page 200.
1296 Fiber rear panel See Figure 131 on page 201.
Table 102 MADI Main and Backup Connections
Note:
• Ensure both Nucleus2 router control modules are configured the same by using the
Copy to Partner function in Workbench once configurations changes have been
made.
