C.6.3.1 5932 Multiviewer Output Module LED Information
Table 111 shows the LED color code on the edge of the 5932 multiviewer output module, and
Figure 222 shows the module.
LED Color Function Detail Normal Working Status
Green Power OK Power to the module On Solid - working
correctly
Yellow Command
OK
Command from the Nucleus Module Flashing - receiving
information and working
correctly
Red Command
Error
Error messages from Nucleus control
module
Off - normal state, if it is
flashing then it is receiving
error messages.
Table 111 5932 Sirius 850 Multiviewer Output Module LED Information
Figure 222 5932 Sirius 850 Multiviewer Output Module LEDs
Power OK Command OK Command Error
5932
