Sirius 800 Series User Manual Outputs Specifications D.2
Iss 5 Rev 7 Page 360 © 2017 SAM
Transparency Default channel status and User data applied to all re-synchronised
outputs.
Default Channel Status bits set to:
• Consumer Use of Channel Status (bit 0) = Professional (1)
• Linear PCM Identification (bit 1) = PCM Data Carried (0) or
Non PCM data carried, e.g. Dolby data (1)
• Sampling Frequency (bits 6 & 7) = 48kHz (0 & 1), 44.1 kHz
(1 & 0) or 32 kHz (1 & 1) or Not Indicated (0, 0)
• Sampling Frequency (bits 35 to 38) = 96 kHz (0, 1, 0, 0),
192 kHz (1, 1, 0, 0) or Not Indicated (0, 0, 0, 0)
• Use of Auxiliary Sample Bits (bit 18) = 24 bit format (1)
• All other default channel status bits set to Zero (0)
Default User Data bits set to:
• All bits set to Zero (0)
Parity re-calculated on outputs.
Transparent to audio data. Sample rate adjustment for near rate
locking by drop/repeat.
Transparency (free
running asynchronous
outputs)
Transparent to audio data.
Transparent to Input Channel Status and User data.
Parity re-calculated on outputs.
MADI Outputs on AES Rear Panel (1353 and 1356 Rear Panel)
Number 3.
Connector HD BNC, 75 electrical impedance.
Impedance 75 ±2
Output Amplitude 720 mV nominal
MADI Outputs on Coax Rear Panel (1295 Rear Panel)
Number and Type 12, with dual outputs per signal.
Connector BNC, 75 electrical impedance.
Impedance 75 ±2
Output Amplitude 720 mV nominal
MADI Outputs on Fiber Rear Panel (1296 Rear Panel)
Number and Type 12 with dual outputs per signal. Removable SFP modules
Fiber Connector LC/PC single mode
Wavelength 1310 nm nominal.
Output Power Typical -2 dBm. Other power and CWDM wavelength options
available - contact factory
Typical Fiber Length
(MADI)
20 km (12.5 Miles) single mode
Note: Fiber MADI specifications are based on fitting standard SFP transmitters
Order Code ST31ST31-3
4929 and 4925- AES/MADI Output Module
Table 120 4929 and 4925 AES/MADI Output Modules
