Sirius 800 Series User Manual Outputs Specifications D.2
Iss 5 Rev 7 Page 359 © 2017 SAM
AES Outputs - Functional
Signal Standard AES3-2009
Output Sample Rate Free running (asynchronous to any reference) the signal input
sample rate is re-generated at the output.
Format 20 bit or 24 bit, as input format
Transparency Default channel status and User data applied to all re-synchronised
outputs.
Default Channel Status bits set to:
• Consumer Use of Channel Status (bit 0) = Professional (1)
• Linear PCM Identification (bit 1) = PCM Data Carried (0) or
Non PCM data carried, e.g. Dolby data (1)
• Sampling Frequency (bits 6 & 7) = 48kHz (0 & 1), 44.1 kHz
(1 & 0) or 32 kHz (1 & 1) or Not Indicated (0, 0)
• Sampling Frequency (bits 35 to 38) = 96 kHz (0, 1, 0, 0),
192 kHz (1, 1, 0, 0) or Not Indicated (0, 0, 0, 0)
• Use of Auxiliary Sample Bits (bit 18) = 24 bit format (1)
• All other default channel status bits set to Zero (0)
Default User Data bits set to:
• All bits set to Zero (0)
Parity re-calculated on outputs.
Transparent to audio data. Sample rate adjustment for near rate
locking by drop/repeat.
Transparency (free
running asynchronous
outputs)
Transparent to audio data.
Transparent to Input Channel Status and User data.
Parity re-calculated on outputs.
AES Outputs Electrical Interface (1353, 1356 and 1298 Rear Panel)
Number and Type 120 AES pairs per card
Balanced AES: 1353 and 1298
Unbalanced AES: 1356
Connector 5 x 62 way high density D type Sockets
Output Amplitude >2V pk-pk into 110
Output Impedance 110 ±10%
Output Rise & Fall
Time
<30 ns
MADI Outputs - Functional
Signal Standard AES10-2003
56 or 64 channels @ 48 kHz sample rate
4929 - see section 11.1.2 for configuration
4925 - see appendix C.4.1.2 for configuration
Sample Rate 48 kHz nominal
Synchronous to the selected reference. AES or video reference 1 to
4 can be selected (AES reference selected by default). Lock to MADI
channel 0 if no reference is present.
Audio Format 20 bit or 24 bit transparent
4929 and 4925- AES/MADI Output Module
Table 120 4929 and 4925 AES/MADI Output Modules
