Sirius 800 Series User Manual Front Module and Rear Panel Compatibility Module Locations 8.1
Iss 5 Rev 7 Page 88 © 2017 SAM
5917
(Section 9.18)
Sirius 800 Standard Video
BNC/Fiber input module
Sirius 830:
1234/1235 BNC, see section 9.1
1372 HD BNC + DS-Link, see
section 9.2
1236 Fiber, see section 9.3
1373 Fiber + DS-Link, see
section 9.4
Sirius 840/850:
1349/1289 BNC, see section 9.9
1305 Fiber, see section 9.11
1360 HD BNC + DS-Link,
see section 9.10
1361 Fiber + DS-Link,
see section 9.12
1362 DS-Link + DS-Link,
see section 9.13
5919*
(Section 9.19)
Sirius 800 Video AHP input module with
delay and sync capability
Sirius 830:
1234/1235 BNC, see section 9.1
1372 HD BNC + DS-Link, see
section 9.2
1236 Fiber, see section 9.3
1373 Fiber + DS-Link, see
section 9.4
Sirius 840/850:
1349/1289 BNC, see section 9.9
1305 Fiber, see section 9.11
1360 HD BNC + DS-Link,
see section 9.10
1361 Fiber + DS-Link,
see section 9.12
1362 DS-Link + DS-Link,
see section 9.13
5926
(Section 11.2)
Sirius 800 Standard Video output module
(non-expandable)
1294 BNC, see section 11.4
1302 Fiber, see section 11.6
1363 HD BNC + DS-Link,
see section 11.5
1364 DS-Link + DS-Link,
see section 11.7
5928
(Section 12.4)
Sirius 850 Standard Video Expansion
output module
Only fitted if expansion of a Sirius 850
frame is required
1290 Expansion Output to a
second Sirius 850 frame,
see section 12.5
1365 Expansion Output to a
second Sirius 850 frame,
see section 12.6
1366 HD BNC,
see section 12.7
5938
(Section 12.3)
Sirius 850 Standard Video output module
(expandable)
Only fitted if expansion is required
between two Sirius 850 frames
1294 BNC, see section 11.4
1302 Fiber, see section 11.6
1363 HD BNC + DS-Link,
see section 11.5
1364 DS-Link + DS-Link,
see section 11.7
Front Module Rear Panel
Table 15 New Router Systems - Front Module and Rear Panel Compatibility (Continued)
To Next Page
