Table 16 shows which front modules and rear panels can be used together on earlier Sirius
800 router systems.
5949*
(Section 11.3)
Sirius 800 Video embedding & AHP output
module with delay and sync capability
1294 BNC, see section 11.4
1302 Fiber, see section 11.6
1363 HD BNC + DS-Link,
see section 11.5
1364 DS-Link + DS-Link,
see section 11.7
5931
(Section 13.6)
Sirius 830/840 External Multiviewer output
module
Sirius 830/840: up to 3 Modules,
Sirius 850: up to 2 modules
Sirius 830/840:
1369 Ext. MV HD BNC,
see section 13.10
Sirius 850:
1370 Ext. MV HD BNC,
see section 13.11
*Early Sirius 800 routers must be modified by SAM before they can be used for audio
routing and processing (4915, 5919, 4929, 5949, 4925, 5915, 5925 or 5903 modules in
use). see section 3.13 to check if the router needs modifying.
Front Module Rear Panel
4925*
(Section C.4.1)
Sirius 800 AES/MADI output module (no audio delay)
120 AES Pairs and up to 3 MADI outputs
(MADI outputs not supported by 1298 rear
panel)
1353 Balanced AES,
see section 11.10
1356 Unbalanced AES,
see section 11.11
1298 Balanced AES,
see Appendix C.5.1
or
12 MADI (Main & Redundant)
1295 BNC, see section 11.8
1296 Fiber, see section 11.9
5913
(Section C.2.1)
Sirius 840/850 Standard Video BNC Input
module
1285 BNC, see section 9.7
5914
(Section C.2.1)
Sirius 840/850 Standard Video Fiber input
module
1286 Fiber, see section 9.8
5915*
(Section C.2.2)
Sirius 800 Video AHP input module
Sirius 830:
1234/1235 BNC, see section 9.1
1372 HD BNC + DS-Link, see
section 9.2
1236 Fiber, see section 9.3
1373 Fiber + DS-Link, see
section 9.4
Sirius 840/850:
1349/1289 BNC, see section 9.9
1305 Fiber, see section 9.11
1360 HD BNC + DS-Link,
see section 9.10
1361 Fiber + DS-Link,
see section 9.12
1362 DS-Link + DS-Link,
see section 9.13
Table 16 Early Router Systems - Front Module and Rear Panel Compatibility
