Sirius 800 Series User Manual Front Module and Rear Panel Compatibility Module Locations 8.1
Iss 5 Rev 7 Page 90 © 2017 SAM
5916
(Section C.2.3)
Sirius 830 Standard Video BNC/Fiber
input module
1234/1235 BNC, see section 9.1
1372 HD BNC + DS-Link, see
section 9.2
1236 Fiber, see section 9.3
1373 Fiber + DS-Link, see
section 9.4
5923
(Section C.4.2)
Sirius 840/850 Standard Video BNC
output module
1295 BNC, see section 11.8
5924
(Section C.4.2)
Sirius 840/850 Standard Video Fiber
output module
1296 Fiber, see section 11.9
5925*
(Section C.4.3)
Sirius 800 Video AHP output module
1294 BNC, see section 11.4
1302 Fiber, see section 11.6
1363 HD BNC + DS-Link,
see section 11.5
1364 DS-Link + DS-Link,
see section 11.7
5937
(Section C.4.4)
Sirius 830 Standard Video BNC/Fiber
output module
1294 BNC, see section 11.4
1302 Fiber, see section 11.6
1363 HD BNC + DS-Link,
see section 11.5
1364 DS-Link + DS-Link,
see section 11.7
5928
(Section 12.4)
Sirius 850 Standard Video Expansion
output module
Only fitted if expansion of a Sirius 850
frame is required
1293 DIN 1.0/2.3 Coax
see Appendix C.7.1
5931
(Section 13.6)
Sirius 830/840 External Multiviewer
output module
Sirius 830/840: up to 3 Modules,
Sirius 850: up to 2 modules
Sirius 830/840:
1309 MV DIN 1.0/2.3 Coax,
see Appendix C.6.1
Sirius 850:
1291 MV DIN 1.0/2.3 Coax,
see Appendix C.6.2
Important:
*Early Sirius 800 routers must be modified by SAM before they can be used for audio
routing and processing (4915, 5919, 4929, 5949, 4925, 5915, 5925 or 5903 modules in
use). see section 3.13 to check if the router needs modifying.
Front Module Rear Panel
Table 16 Early Router Systems - Front Module and Rear Panel Compatibility
