SATO FX3-LX - Media Sensor Type

127
Media Sensor Type
The printer adjusts the print position precisely by detecting I-marks or Gaps on the media (label) using
media sensors.
The I-marks or Gaps on each type of media are as follows:
Label Type Position
Center I-mark
(1) Media feed direction
Bottom I-mark
(1) Media feed direction
Top I-mark
(1) Media feed direction
I-mark Label
Labels with I-marks other than our specifications
(Custom I-mark)
