SATO FX3-LX User Manual

395
List of Initial Values
[Printing] Menu
The initial value refers to the setting value of the printer when it was shipped from the factory. The
table below shows the initial value of each setting item.
Setting Item Initial Value
[Label Length] 6000 dots
[Label Width] 960 dots
[Auto Measure] Disabled
[Speed] 4 ips (If the printer is connected to AC power)
3 ips (If only the optional battery is installed)
[Sensor Type] I-Mark (When [Print Mode] is [Dispenser],
[Tear-Off], [Continuous], [Cutter], or [Partial
cutter])
None (When [Print Mode] is [Linerless tearoff]
or [Linerless cutter])
[I-Mark Position] Bottom I-Mark
[Label Size] 25 mm
[I-Mark Offset] 0 dot
[Auto-mode] Enabled
[Print Mode]
If [Auto-mode] is enabled
Dispenser (If no option is installed and
media is loaded for dispenser mode)
Tear-Off (If no option is installed and media
is loaded for continuous/tear-off mode)
Cutter (If cutter kit is installed)
Partial cutter (If partial cutter kit is installed)
If [Auto-mode] is disabled
Tear-Off
[Backfeed] Before (If [Print Mode] is set to [Tear-Off] or
[Partial cutter])
After (If [Print Mode] is set to [Dispenser],
[Cutter], [Linerless tearoff], or [Linerless
cutter])
None (If [Print Mode] is set to [Continuous])

SATO FX3-LX Specifications

General

Cutter	Yes
Certification	EN55032, EN55024, EN61000-3-2 / 3-3, EN300 330-2 / -1, EN301 489-1 / -3 / -17, FCC Part15 Subpart B, ICES 003 UL60950-1, CSA C22.2 No.60950-1, IEC/EN60950-1 FCC Part15 Subpart C/E, ISED RSS-Gen, ISED RSS-247, EN 300 328, EN 301 893
Built-in barcodes	AZTECCODE, CODABAR (NW-7), Code 128 (A/B/C), Code 39, Code 93, Data Matrix, EAN13, EAN8, GS1 COMPOSITE, GS1 DataBar, GS1-128, Industrial 2/5, Interleaved 2/5, Matrix 2/5, MaxiCode, Micro QR Code, MicroPDF417, PDF417, POSTNET, QR Code, UPC-A, UPC-E
Built-in RFID module	No
Maximum resolution	- DPI
Maximum print height	500 mm
Maximum printing width	80 mm
Battery voltage	14.4 V
AC input voltage	100 - 240 V
Battery capacity	1950 mAh
AC input frequency	50 / 60 Hz
Suitable for use in country/location	Europe
Sustainability certificates	ENERGY STAR
Display	LCD
Control type	Touch
Product color	White
Display diagonal	7 \
Display resolution	480 x 800 pixels
International Protection (IP) code	IPX2
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.1
USB 2.0 ports quantity	4
Connectivity technology	Wired & Wireless
Media thickness	0.14 - 0.19 mm
Maximum roll diameter	105 mm
Storage temperature (T-T)	-5 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 75 %
Cables included	AC
Quantity per pack	1 pc(s)
Languages support	Multi

Weight and Dimensions

Depth	225 mm
Width	132 mm
Height	180 mm
Weight	3000 g
