SATO FX3-LX User Manual

261
The setting items are as follows:
[Additional]
Set the additional ARP announcement.
Enable the additional ARP announcement. The ARP is sent at 1, 2, 4, 8 and 16 seconds after the
link up/DHCP assignment.
Disable the additional ARP announcement. The ARP is only sent at 1 second after the link up/
DHCP assignment.
[Periodic]
Set the interval of the ARP announcement in the range of 0 to 600 seconds.
Initial setting: 0
• The function is disabled if you set it to 0.
[USB]
Set the USB connection.
The setting items are as follows:
[Flow Control]
Set the communication protocol.
The options are as follows:
• [STATUS4]
• [STATUS5]
• [NONE]
[BCC]
Enable or disable the BCC check function.
Appears only if you have selected [STATUS5] in the [Flow Control] menu.
[Change USB Serial]
Set the type of the USB serial number that the printer returns.
Returns the USB serial number (00000000).
This option is suitable when you want to replace the printer without adding a new printer driver.
To do so, you need to set this setting to enabled before installing the printer.

SATO FX3-LX Specifications

General

Cutter	Yes
Certification	EN55032, EN55024, EN61000-3-2 / 3-3, EN300 330-2 / -1, EN301 489-1 / -3 / -17, FCC Part15 Subpart B, ICES 003 UL60950-1, CSA C22.2 No.60950-1, IEC/EN60950-1 FCC Part15 Subpart C/E, ISED RSS-Gen, ISED RSS-247, EN 300 328, EN 301 893
Built-in barcodes	AZTECCODE, CODABAR (NW-7), Code 128 (A/B/C), Code 39, Code 93, Data Matrix, EAN13, EAN8, GS1 COMPOSITE, GS1 DataBar, GS1-128, Industrial 2/5, Interleaved 2/5, Matrix 2/5, MaxiCode, Micro QR Code, MicroPDF417, PDF417, POSTNET, QR Code, UPC-A, UPC-E
Built-in RFID module	No
Maximum resolution	- DPI
Maximum print height	500 mm
Maximum printing width	80 mm
Battery voltage	14.4 V
AC input voltage	100 - 240 V
Battery capacity	1950 mAh
AC input frequency	50 / 60 Hz
Suitable for use in country/location	Europe
Sustainability certificates	ENERGY STAR
Display	LCD
Control type	Touch
Product color	White
Display diagonal	7 \
Display resolution	480 x 800 pixels
International Protection (IP) code	IPX2
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.1
USB 2.0 ports quantity	4
Connectivity technology	Wired & Wireless
Media thickness	0.14 - 0.19 mm
Maximum roll diameter	105 mm
Storage temperature (T-T)	-5 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 75 %
Cables included	AC
Quantity per pack	1 pc(s)
Languages support	Multi

Weight and Dimensions

Depth	225 mm
Width	132 mm
Height	180 mm
Weight	3000 g
