SATO FX3-LX User Manual

[Network]
260
Horizontal
Specify the offset position of the QR code in the horizontal direction.
Set the correction value from the standard printing position when facing the printer as "-" to adjust
to the right side and "+" to adjust to the left side.
(1) Feed direction
The setting range is from -792 to +792 dots.
• The length of 1 dot is 0.083 mm (0.0033").
• You can change the unit to dots or inches in the [System] > [Regional] > [Unit] menu.
[SOS Update] (SOS users only)
Shows the current printer information with a QR code. Scan the QR code with a tablet or smartphone,
and send it to the SOS cloud.
Appears only if you have selected [On-Demand] in the [SOS Mode] menu.
A specialized application is required to scan the QR code.
If you have selected [Print] in the [Update Screen], tap [PRINT] to print the QR code.
To print the QR code, use media of more than 40 mm (1.57") in length and more than 40 mm (1.57") in
width (not including the liner).
[Advanced]
Set the advanced function for the interface.
The setting item is as follows:
[ARP Announcement]
Set the functions for ARP announcement.
The ARP announcement is useful for updating other hosts mapping of a hardware address when the
IP address or MAC address of the sender has changed.

SATO FX3-LX Specifications

General

Cutter	Yes
Certification	EN55032, EN55024, EN61000-3-2 / 3-3, EN300 330-2 / -1, EN301 489-1 / -3 / -17, FCC Part15 Subpart B, ICES 003 UL60950-1, CSA C22.2 No.60950-1, IEC/EN60950-1 FCC Part15 Subpart C/E, ISED RSS-Gen, ISED RSS-247, EN 300 328, EN 301 893
Built-in barcodes	AZTECCODE, CODABAR (NW-7), Code 128 (A/B/C), Code 39, Code 93, Data Matrix, EAN13, EAN8, GS1 COMPOSITE, GS1 DataBar, GS1-128, Industrial 2/5, Interleaved 2/5, Matrix 2/5, MaxiCode, Micro QR Code, MicroPDF417, PDF417, POSTNET, QR Code, UPC-A, UPC-E
Built-in RFID module	No
Maximum resolution	- DPI
Maximum print height	500 mm
Maximum printing width	80 mm
Battery voltage	14.4 V
AC input voltage	100 - 240 V
Battery capacity	1950 mAh
AC input frequency	50 / 60 Hz
Suitable for use in country/location	Europe
Sustainability certificates	ENERGY STAR
Display	LCD
Control type	Touch
Product color	White
Display diagonal	7 \
Display resolution	480 x 800 pixels
International Protection (IP) code	IPX2
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.1
USB 2.0 ports quantity	4
Connectivity technology	Wired & Wireless
Media thickness	0.14 - 0.19 mm
Maximum roll diameter	105 mm
Storage temperature (T-T)	-5 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 75 %
Cables included	AC
Quantity per pack	1 pc(s)
Languages support	Multi

Weight and Dimensions

Depth	225 mm
Width	132 mm
Height	180 mm
Weight	3000 g
