Installing the Optional Cutter Kit/Partial Cutter Kit
84
Installing the Options
Installing the Optional Cutter Kit/Partial Cutter Kit
• Do not connect or disconnect the power cord while your hands are wet. Doing so could
cause an electric shock.
• Do not touch the terminals with wet hands.
• Touching the edge of the print head with your bare hand could cause injury.
• Be careful not to touch the cutter blade.
1. Make sure that the printer is powered off, and disconnect the power cord from the
AC outlet or remove the optional battery.
2. Press the cover open button (1) to open the top cover (2).
3. While pushing the lock buttons (3) on both sides, tilt the dispenser kit (4) toward
the front to remove it.
