SATO FX3-LX User Manual

Usable Media
498
Usable Media
• Use our specified supply products.
Type
• Media roll (Face-in wound/face-out wound)
• Fan-fold media
Size
• Continuous/Tear-Off/Cutter/Partial Cutter/Dispenser
Item Description
Media Length 16 to 500 mm (0.63" to 19.69")
Media Length (With Liner) 19 to 503 mm (0.75" to 19.80")
Media Width 25 to 82 mm (0.98" to 3.23")
Media Width (With Liner) 28 to 82 mm (0.98" to 3.23") (butt cut label) / 28 to 85 mm (1.10" to
3.35") (others)
• Above pitch and width are valid for die-cut labels. For media without liner like tags,
refer to the value 'with liner'.
• Linerless
Item Description
Media Length 20 to 500 mm (0.79" to 19.69")
Media Width 32 to 82 mm (1.26" to 3.23")
• Linerless Cutter
Item Description
Media Length 45 to 500 mm (1.77" to 19.69")
Media Width 32 to 82 mm (1.26" to 3.23")
• The usable media sizes, the output speed and print quality vary depending on
the media specification, media, printer settings and outputting environment. It is
recommended to perform a test print with the media to be used in advance.

SATO FX3-LX Specifications

General

Cutter	Yes
Certification	EN55032, EN55024, EN61000-3-2 / 3-3, EN300 330-2 / -1, EN301 489-1 / -3 / -17, FCC Part15 Subpart B, ICES 003 UL60950-1, CSA C22.2 No.60950-1, IEC/EN60950-1 FCC Part15 Subpart C/E, ISED RSS-Gen, ISED RSS-247, EN 300 328, EN 301 893
Built-in barcodes	AZTECCODE, CODABAR (NW-7), Code 128 (A/B/C), Code 39, Code 93, Data Matrix, EAN13, EAN8, GS1 COMPOSITE, GS1 DataBar, GS1-128, Industrial 2/5, Interleaved 2/5, Matrix 2/5, MaxiCode, Micro QR Code, MicroPDF417, PDF417, POSTNET, QR Code, UPC-A, UPC-E
Built-in RFID module	No
Maximum resolution	- DPI
Maximum print height	500 mm
Maximum printing width	80 mm
Battery voltage	14.4 V
AC input voltage	100 - 240 V
Battery capacity	1950 mAh
AC input frequency	50 / 60 Hz
Suitable for use in country/location	Europe
Sustainability certificates	ENERGY STAR
Display	LCD
Control type	Touch
Product color	White
Display diagonal	7 \
Display resolution	480 x 800 pixels
International Protection (IP) code	IPX2
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.1
USB 2.0 ports quantity	4
Connectivity technology	Wired & Wireless
Media thickness	0.14 - 0.19 mm
Maximum roll diameter	105 mm
Storage temperature (T-T)	-5 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 75 %
Cables included	AC
Quantity per pack	1 pc(s)
Languages support	Multi

Weight and Dimensions

Depth	225 mm
Width	132 mm
Height	180 mm
Weight	3000 g
