SATO FX3-LX User Manual

[Install Certificates]
304
[Factory]
These are the setting items for factory.
Strictly for SATO authorized service personnel use.
[Wi-Fi Site Survey]
Make a survey of the wave strength for each access point and display or print the survey results.
Appears only when the optional wireless LAN/Bluetooth kit is installed.
The options are as follows:
SiteSurveyDisp.
Shows the wave strength for each access point.
SiteSurveyPrint
Prints the wave strength for each access point.
[Install Certificates]
Install certificates used for Wi-Fi authentication and for HTTPS.
Available only if you have connected the USB memory.
• Be sure to perform a virus check on the USB memory before connecting it to the
printer. SATO Corporation shall not be held responsible for any printer malfunctions
caused by a virus spread via USB memory.
The setting items are as follows:
HTTPS
Installs the HTTPS certificates from the USB memory.
Wi-Fi Root CA
Installs the Wi-Fi Root CA certificates from the USB memory.
Wi-Fi Client
Installs the Wi-Fi client certificates from the USB memory.
Wi-Fi Private Key
Installs the Wi-Fi private key from the USB memory.
EAP-FAST PAC File
Installs the EAP-FAST PAC file from the USB memory.
SFTP/SCP Server
Installs the SFTP/SCP server certificates from the USB memory.
FTPS/SCP Client
Installs the FTPS/SCP client certificates from the USB memory.

SATO FX3-LX Specifications

General

Cutter	Yes
Certification	EN55032, EN55024, EN61000-3-2 / 3-3, EN300 330-2 / -1, EN301 489-1 / -3 / -17, FCC Part15 Subpart B, ICES 003 UL60950-1, CSA C22.2 No.60950-1, IEC/EN60950-1 FCC Part15 Subpart C/E, ISED RSS-Gen, ISED RSS-247, EN 300 328, EN 301 893
Built-in barcodes	AZTECCODE, CODABAR (NW-7), Code 128 (A/B/C), Code 39, Code 93, Data Matrix, EAN13, EAN8, GS1 COMPOSITE, GS1 DataBar, GS1-128, Industrial 2/5, Interleaved 2/5, Matrix 2/5, MaxiCode, Micro QR Code, MicroPDF417, PDF417, POSTNET, QR Code, UPC-A, UPC-E
Built-in RFID module	No
Maximum resolution	- DPI
Maximum print height	500 mm
Maximum printing width	80 mm
Battery voltage	14.4 V
AC input voltage	100 - 240 V
Battery capacity	1950 mAh
AC input frequency	50 / 60 Hz
Suitable for use in country/location	Europe
Sustainability certificates	ENERGY STAR
Display	LCD
Control type	Touch
Product color	White
Display diagonal	7 \
Display resolution	480 x 800 pixels
International Protection (IP) code	IPX2
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.1
USB 2.0 ports quantity	4
Connectivity technology	Wired & Wireless
Media thickness	0.14 - 0.19 mm
Maximum roll diameter	105 mm
Storage temperature (T-T)	-5 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 75 %
Cables included	AC
Quantity per pack	1 pc(s)
Languages support	Multi

Weight and Dimensions

Depth	225 mm
Width	132 mm
Height	180 mm
Weight	3000 g
