Installing the Optional Wall Mount Kit
92
Installing the Optional Wall Mount Kit
Preparation for Installing the Optional Wall Mount Kit
• We are not liable for the printer falling due to the installation not being strong enough.
Confirming the condition of the wall and installing the printer is your responsibility.
• Handle the printer with care.
Required tools and screws
• Phillips screwdriver
• Screws for securing the mount bracket on the wall (x4)
Notes on the selection of screws to prepare
• Select four screws of which shear strength and pull-out strength are sufficient for a load of 22 kgf
(216 N) or more. (Major diameter 3.5 mm (0.14") or larger)
• Select screws suitable for the wall to securely mount the printer on it.
Notes on the location of installation
• Choose a flat location not subject to water leaks or shock, and secure the mount bracket on it.
• Keep 150 mm (5.91") or more space around the printer.
• The battery mount kit and cradle kit cannot be used when the printer is mounted on the wall
mount kit.
Installing the Wall Mount Kit
• Do not connect or disconnect the power cord while your hands are wet. Doing so could
cause an electric shock.
• Carefully handle the wall mount kit so that you may be not injured by its sharp edges.
• When mounting the printer on the wall mount kit, be cautious so that your fingers are
not caught in between.
• When mounting the printer on the mount kit, hold the printer with both hands.
Otherwise, you may be injured by the printer fallen.
1. Attach the joint plate to the printer.
a. Turn over the printer on a clean level surface.
b. Insert the hooks (2) on the joint plate (1) into the hook slots (3) on the printer.
c. Slide the joint plate in the direction of the arrow shown in the illustration.
d. Secure the joint plate with the supplied screws (4).
