193
Loading the Media Roll
Loading the Media Roll (Printing in Continuous Mode/Tear-Off Mode)
• The print head and its surroundings are hot after printing. Be careful not to touch it, to
avoid being burned. Do not replace the media immediately after printing.
• Touching the edge of the print head with your bare hand could cause injury.
1. Press the cover open button (1) to open the top cover (2).
2. While pushing the slide lever (3), move the media guide (4) which is on the right
side to adjust its width to match the width of the media roll.
• Do not load the media roll yet.
• Change the flap position of the media guide in accordance with the core diameter of
the media roll.
