Loading the Fan-fold Media
212
Loading the Fan-fold Media
• The print head and its surroundings are hot after printing. Be careful not to touch it, to
avoid being burned. Do not replace the media immediately after printing.
• Touching the edge of the print head with your bare hand could cause injury.
• Fan-fold media is not available in dispenser mode since the perforated line affects the
dispenser function.
1. Open the media loading port (1) on the back of the printer.
2. Insert the fan-fold media from the media loading port.
(A) Media height (from desk): within 100 mm (3.94")
(B) Distance between the back side of the printer and the media: 150 mm (5.91") or more
• When loading the media, make sure that the label side faces up.
• The height may be limited depending on where media is placed.
• When drawing the media from under the desk, not from the position on the same desk
which the rear side of the printer is placed, place the media so as not to obstruct the
printing operation.
To Next Page
