SATO FX3-LX User Manual

313
[Cycle Counts]
Shows the cycle count (charge/discharge cycle).
[Eco Charge]
Enable or disable the Eco Charge function.
The Eco Charge function is designed to extend the battery life by keeping the after-charged volume of
the battery a little lower than the fully charged volume, thus delaying the degree of deterioration.
• When using the printer with the optional cradle kit, it is recommended to enable the
Eco Charge function.
[Full Charge Power-Off]
Set up the printerʼs power-off function after charging is complete.
While the printer is paused in Online/Offline screen, the printer powers off 3 seconds after it completes
charging.
Conditions to disable the Fully-Charge Power-Off function
• While the printer is printing or feeding the media.
• While the printer button is being used.
• During Adjustments or Settings mode.
• While the printer receives the data.
• When an AC adapter is removed.
• When the printer has restarted charging after a certain amount of battery discharge.
• While an error related to the battery is occurring.
• When using the printer with the optional cradle kit, it is recommended to enable the Full
Charge Power-Off function.
• The printer powers off even if an error has occurred, if there is no change in the error
status.

SATO FX3-LX Specifications

General

Cutter	Yes
Certification	EN55032, EN55024, EN61000-3-2 / 3-3, EN300 330-2 / -1, EN301 489-1 / -3 / -17, FCC Part15 Subpart B, ICES 003 UL60950-1, CSA C22.2 No.60950-1, IEC/EN60950-1 FCC Part15 Subpart C/E, ISED RSS-Gen, ISED RSS-247, EN 300 328, EN 301 893
Built-in barcodes	AZTECCODE, CODABAR (NW-7), Code 128 (A/B/C), Code 39, Code 93, Data Matrix, EAN13, EAN8, GS1 COMPOSITE, GS1 DataBar, GS1-128, Industrial 2/5, Interleaved 2/5, Matrix 2/5, MaxiCode, Micro QR Code, MicroPDF417, PDF417, POSTNET, QR Code, UPC-A, UPC-E
Built-in RFID module	No
Maximum resolution	- DPI
Maximum print height	500 mm
Maximum printing width	80 mm
Battery voltage	14.4 V
AC input voltage	100 - 240 V
Battery capacity	1950 mAh
AC input frequency	50 / 60 Hz
Suitable for use in country/location	Europe
Sustainability certificates	ENERGY STAR
Display	LCD
Control type	Touch
Product color	White
Display diagonal	7 \
Display resolution	480 x 800 pixels
International Protection (IP) code	IPX2
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.1
USB 2.0 ports quantity	4
Connectivity technology	Wired & Wireless
Media thickness	0.14 - 0.19 mm
Maximum roll diameter	105 mm
Storage temperature (T-T)	-5 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 75 %
Cables included	AC
Quantity per pack	1 pc(s)
Languages support	Multi

Weight and Dimensions

Depth	225 mm
Width	132 mm
Height	180 mm
Weight	3000 g
