429
Replacing the Platen Roller
You can easily remove and replace a damaged or worn platen roller.
• Do not connect or disconnect the power cord while your hands are wet. Doing so could
cause an electric shock.
• Disconnect the power cord from the AC outlet or remove the optional battery before
you replace the consumable parts.
1. Make sure that the printer is powered off, and disconnect the power cord from the
AC outlet or remove the optional battery.
2. Press the cover open button (1) to open the top cover (2).
3. Remove the media if it is already loaded.
4. Push the two tabs (3) toward the back to remove the inner cover (4).
To Next Page
