Parts Identification
34
Parts Identification
Front View
(1) LCD/Touch panel
(2) LED indicator
(3) / (Standby/Home) button
To power on the printer, press the / (Standby/Home) button until the LED lights blue.
Press the / (Standby/Home) button when the printer is powered on to switch to the Home
screen. (The Home screen does not appear when print jobs remain in the printer.)
To power off the printer, press the / (Standby/Home) button for more than two seconds
and follow the on-screen instructions.
(4) NFC built-in antenna
(5) Cover open button
(6) Media discharge outlet
(7) Liner discharge outlet
(8) Top cover
(9) Operator panel
(10) Handle
