SATO FX3-LX User Manual

Configuring the Interface Settings from the Settings Mode of the Printer
146
Configuring the Interface Settings
Interface Setting Methods
Configure the interface settings of the printer according to the communication conditions of the
connected network and computer.
You can set the interface settings of the printer doing either of the following.
• Set from the Settings mode of the printer
• Set using the All-In-One Tool from the computer
Configuring the Interface Settings from the Settings Mode of the Printer
Configure the settings related to the interfaces from the [Interface] menu, [Bluetooth] menu, or [Wi-Fi]
menu of the Settings mode of the printer.
1.
Tap on the Home screen or Offline screen to show the [Settings] menu.
2. Input the password if it is enabled.
3. Tap [Interface], [Bluetooth], or [Wi-Fi].
To configure settings related to LAN/USB/NFC connections or CR/LF, CAN/DLE codes, tap
[Interface].
To configure settings related to Bluetooth, tap [Bluetooth].

SATO FX3-LX Specifications

General

Cutter	Yes
Certification	EN55032, EN55024, EN61000-3-2 / 3-3, EN300 330-2 / -1, EN301 489-1 / -3 / -17, FCC Part15 Subpart B, ICES 003 UL60950-1, CSA C22.2 No.60950-1, IEC/EN60950-1 FCC Part15 Subpart C/E, ISED RSS-Gen, ISED RSS-247, EN 300 328, EN 301 893
Built-in barcodes	AZTECCODE, CODABAR (NW-7), Code 128 (A/B/C), Code 39, Code 93, Data Matrix, EAN13, EAN8, GS1 COMPOSITE, GS1 DataBar, GS1-128, Industrial 2/5, Interleaved 2/5, Matrix 2/5, MaxiCode, Micro QR Code, MicroPDF417, PDF417, POSTNET, QR Code, UPC-A, UPC-E
Built-in RFID module	No
Maximum resolution	- DPI
Maximum print height	500 mm
Maximum printing width	80 mm
Battery voltage	14.4 V
AC input voltage	100 - 240 V
Battery capacity	1950 mAh
AC input frequency	50 / 60 Hz
Suitable for use in country/location	Europe
Sustainability certificates	ENERGY STAR
Display	LCD
Control type	Touch
Product color	White
Display diagonal	7 \
Display resolution	480 x 800 pixels
International Protection (IP) code	IPX2
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.1
USB 2.0 ports quantity	4
Connectivity technology	Wired & Wireless
Media thickness	0.14 - 0.19 mm
Maximum roll diameter	105 mm
Storage temperature (T-T)	-5 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 75 %
Cables included	AC
Quantity per pack	1 pc(s)
Languages support	Multi

Weight and Dimensions

Depth	225 mm
Width	132 mm
Height	180 mm
Weight	3000 g
