NFC Interface Connection (Standard)
142
(4) Wireless LAN/Bluetooth (optional)
The NFC interface supports the handover function that simplifies the Bluetooth/Wi-Fi
connection setup with Android devices. In addition, the NFC interface can be used for
changing printer settings with an Android device while the printer is powered off and
the power cord is not connected.
USB Interface Connection (Standard)
Connect the interface cable when the printer is powered off.
Connect the USB cable to the USB connector (Type B) (1) of the printer.
The USB interface is selected after connecting the USB cable to the computer and the printer, and
powering on the printer while the computer is turned on.
If the printer is powered on without installing the printer driver, Windows' Plug & Play
runs. When using the printer driver, do not power on the printer while the USB cable is
connected until instructed in the procedure for installing the printer driver.
The recommended USB cable is the one within 5 meters (16.4 feet) length.
NFC Interface Connection (Standard)
The NFC interface of the printer supports a handover function that simplifies the Bluetooth/Wi-Fi
connection setup with Android devices.
The handover function only performs the connection setup, such as the pairing and authentication with
NFC, and passes the actual interface to the more advanced Bluetooth and Wi-Fi when communicating
between NFC supported devices. In general, the pairing and authentication require some procedures
to enter authentication information, but the connection can be completed simply by holding the Android
devices over the printer while using NFC.
Touch the NFC antenna (1) of the printer with the NFC mark on the Android device.

Table of Contents

Other manuals for SATO FX3-LX

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the SATO FX3-LX and is the answer not in the manual?

SATO FX3-LX Specifications

General IconGeneral
CutterYes
CertificationEN55032, EN55024, EN61000-3-2 / 3-3, EN300 330-2 / -1, EN301 489-1 / -3 / -17, FCC Part15 Subpart B, ICES 003 UL60950-1, CSA C22.2 No.60950-1, IEC/EN60950-1 FCC Part15 Subpart C/E, ISED RSS-Gen, ISED RSS-247, EN 300 328, EN 301 893
Built-in barcodesAZTECCODE, CODABAR (NW-7), Code 128 (A/B/C), Code 39, Code 93, Data Matrix, EAN13, EAN8, GS1 COMPOSITE, GS1 DataBar, GS1-128, Industrial 2/5, Interleaved 2/5, Matrix 2/5, MaxiCode, Micro QR Code, MicroPDF417, PDF417, POSTNET, QR Code, UPC-A, UPC-E
Built-in RFID moduleNo
Maximum resolution- DPI
Maximum print height500 mm
Maximum printing width80 mm
Battery voltage14.4 V
AC input voltage100 - 240 V
Battery capacity1950 mAh
AC input frequency50 / 60 Hz
Suitable for use in country/locationEurope
Sustainability certificatesENERGY STAR
DisplayLCD
Control typeTouch
Product colorWhite
Display diagonal7 \
Display resolution480 x 800 pixels
International Protection (IP) codeIPX2
Wi-Fi standards802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version4.1
USB 2.0 ports quantity4
Connectivity technologyWired & Wireless
Media thickness0.14 - 0.19 mm
Maximum roll diameter105 mm
Storage temperature (T-T)-5 - 60 °C
Operating temperature (T-T)5 - 35 °C
Storage relative humidity (H-H)30 - 90 %
Operating relative humidity (H-H)30 - 75 %
Cables includedAC
Quantity per pack1 pc(s)
Languages supportMulti
Weight and Dimensions IconWeight and Dimensions
Depth225 mm
Width132 mm
Height180 mm
Weight3000 g
