Page #286 background imageLoading...
Page #286 background image
[Energy Saving]
286
[Sound]
Set the volume and the key sounds.
The setting items are as follows:
[Volume]
Set the volume for the printer sounds, such as the error buzzer and key sound.
The setting range is from 0 to 8.
0 is the lowest and 8 is the highest.
If you set the volume to 0, it mutes the sound.
You can set this item from the swipe down menu as well.
[Key Sound]
Set the type of sounds when a key is tapped.
The options are as follows:
None
Mute key sounds.
Key Sound1
Key Sound2
Key Sound3
[Energy Saving]
The setting items are as follows:
[AC (Without Battery)]
Set the Energy Saving function when using the AC power supply.
The setting items are as follows:
[Sleep Timeout]
Set the period before the printer enters sleep mode.
The setting range is from 0 to 60 minutes.
The sleep function is disabled if you set it to 0.
Conditions Not to Transit to Sleep Mode
While the Home screen is shown or during Settings mode
When the temperature in the printer exceeds the tolerance range (Error 1022)
When the printer is connected by wireless LAN ad-hoc mode or Wi-Fi Direct

Table of Contents

Other manuals for SATO FX3-LX

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the SATO FX3-LX and is the answer not in the manual?

SATO FX3-LX Specifications

General IconGeneral
CutterYes
CertificationEN55032, EN55024, EN61000-3-2 / 3-3, EN300 330-2 / -1, EN301 489-1 / -3 / -17, FCC Part15 Subpart B, ICES 003 UL60950-1, CSA C22.2 No.60950-1, IEC/EN60950-1 FCC Part15 Subpart C/E, ISED RSS-Gen, ISED RSS-247, EN 300 328, EN 301 893
Built-in barcodesAZTECCODE, CODABAR (NW-7), Code 128 (A/B/C), Code 39, Code 93, Data Matrix, EAN13, EAN8, GS1 COMPOSITE, GS1 DataBar, GS1-128, Industrial 2/5, Interleaved 2/5, Matrix 2/5, MaxiCode, Micro QR Code, MicroPDF417, PDF417, POSTNET, QR Code, UPC-A, UPC-E
Built-in RFID moduleNo
Maximum resolution- DPI
Maximum print height500 mm
Maximum printing width80 mm
Battery voltage14.4 V
AC input voltage100 - 240 V
Battery capacity1950 mAh
AC input frequency50 / 60 Hz
Suitable for use in country/locationEurope
Sustainability certificatesENERGY STAR
DisplayLCD
Control typeTouch
Product colorWhite
Display diagonal7 \
Display resolution480 x 800 pixels
International Protection (IP) codeIPX2
Wi-Fi standards802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version4.1
USB 2.0 ports quantity4
Connectivity technologyWired & Wireless
Media thickness0.14 - 0.19 mm
Maximum roll diameter105 mm
Storage temperature (T-T)-5 - 60 °C
Operating temperature (T-T)5 - 35 °C
Storage relative humidity (H-H)30 - 90 %
Operating relative humidity (H-H)30 - 75 %
Cables includedAC
Quantity per pack1 pc(s)
Languages supportMulti
Weight and Dimensions IconWeight and Dimensions
Depth225 mm
Width132 mm
Height180 mm
Weight3000 g
