Replacing the Print Head
428
4. Tilt the top cover (2) toward the front to remove the print head (5).
• Do not touch the heating unit and terminals of the print head.
5. Install the new print head and close the head cover.
• Handle the print head with care. Do not contaminate or scratch the sensitive print head
surface.
6. Close the top cover.
Push both ends of the top cover, and close it firmly until it clicks.
• When closing the top cover, be careful not to pinch your fingers.
