Loading the Media Roll (Printing in Dispenser Mode)
198
(A) About 10 cm (3.94")
5. Pass the media below the tabs (8).
6.
Lift the dispenser frame (9) on the front of the printer ( ) and tilt it toward the
front ( ).
7. Pass the liner through the gap (opening) between the dispenser frame and the
printer to the outside of the printer ( ), and close the dispenser frame ( ).
To Next Page
